Shell Kit

for Ecolift, w/o socket

21000-RBK
21000-RBK
PDF product data sheet

KESSEL Shell Kit for Ecolift, w/o socket, wastewater with sewage, exposed drainage pipe, with submersible pumps

Item no. 21000-RBK
GTIN 4026092097144
Price group 20

    Shell Kit for Ecolift, w/o socket
    KESSEL shell kit for Ecolift, without sockets Shell kit consisting of a drain body and upper section. The inlet and outlet sockets are not included. For combination with a KESSEL technology kit for creating an Ecolift backwater lifting station. General characteristics Colour: black Type of wastewater: with sewage Installation situation: exposed drainage pipe Delivery state: Pre-mounted for final assembly on site (pumps and sensor system must be fitted on site and control unit must be connected) Approval: Z-53.2-487 Motor type: KSM 140 Type de protection moteur: IP 68 (3m/48h) ATEX: no Dimensions Net weight: 8 kg Gross weight: 8,36 kg Groundwater resistant from lower edge of base section: 2000 mm Installation depth: 516 - 669 mm Length: 405 mm Width: 243 mm Height: 405 mm Packaging dimension: length: 785 mm Packaging dimension: width: 385 mm Packaging dimension: height: 465 mm Tank/drain body Nominal pressure (PN): 6 Pressure pipe connection (OD): 40 mm Socket version: optional
      Title Item no.
      Title Item no.
      Title Item no.
      Title Item no.
    21056 Lockable cover Ecolift Outlet side 21056 Show
    28052 Lockable cover Inlet side 28052 Show
    28060 Ventilation with activated carbon filter 28060 Show
    28061 Active carbon filter 5 each 28061 Show
    28071 Control unit Comfort 230 V, Ecolift, Pumpfix F from 01/2011 28071 Show
    28351 Replacement pump KTP/SPZ 1000 230 V, cable length 5 m 28351 Show
    680018 One-handed closure for backflow preventer 680018 Show
    680034 Battery 9 V block 680034 Show
    680101 Flap holder for motor-driven and mechanical flap 680101 Show
    680102 Pressure pipe connection Ecolift, installation with exposed pipe 680102 Show
    70319 Seal set Pumpfix, Ecolift 70319 Show
    80038 Backwater flap motor-driven, with flap holder 80038 Show
    80039 Slide-in flap housing for motorised flap with flap holder 80039 Show
    80076 Drive motor plug-in ready, 5 m cable 80076 Show
    80888 Spare part set, optical probe 5 m cable 80888 Show
    80892 Adapter Set optical probe 80892 Show
    • (abdeckungsart):
    • Installation situation (einbausituation): exposed drainage pipe
    • Type of wastewater (abwasserart_de): with sewage
