Replacement pump GTF 600

without float switch, 5 m

680977
PDF product data sheet

Replacement pump with float switch for faecal-free wastewater.

Item no. 680977
GTIN 4026092095904
Price group 90

    Replacement pump GTF 600 without float switch, 5 m
    Replacement pump with float switch for faecal-free wastewater. General characteristics Type of wastewater: without sewage Dimensions Net weight: 6,35 kg Gross weight: 6,35 kg Packaging dimension: length: 276 mm Packaging dimension: width: 241 mm Packaging dimension: height: 265 mm Pumping device Pump: GTF 600 Connection type: Schuko (earthed contact) 2-pin Operating voltage: 230 V Mains frequency: 50 Hz Rated current: 2,9 A Protection class (pump): IP 68 (3m) Max. temperature (permanent) of conveyed material: 40 °C Max. pumping height: 8 m Speed: 2750 U/min Power P1: 0,65 kW Power P2: 0,4 kW Operating mode: S1 Type of fuse required (electrical protection): C 16 A Type of pump connection cable: H07RN-F 3G 1.5 mm² Impeller type: Multi-vane impeller Length of mains cable for pump: 10 m Control Connection type: Schuko (earthed contact) 2-pin Type of fuse required (electrical protection): C 16 A
      Title Item no.
      Title Item no.
      Title Item no.
      Title Item no.
    Declaration of Conformity
    • Type of wastewater (abwasserart_de): without sewage
